Your present location:index >> Product classification >> 1TS017 Series >>1TS017D

product name: Top push SMD3.7*3.7*0.4mm
Product Number: 1TS017D
Material: POLYAMIDE/BRONZE/STAINLESS STEEL
Scope of application: earphones, small instruments, 3C digital products, medical instruments

Low-cost solutions: earphones, small instruments, 3C digital products, medical instruments

Reference alternative:

Item	Tact switch detail	Tact switch detail 2
Article number	1TS017D	1TS017D
Model	1TS017D	1TS017D
Series	1TS017	1TS017
(LxW) (mm)	3.7*3.7mm	3.7*3.7mm
(H) (mm)	0.4±0.1mm	0.4±0.1mm
Installation height (mm)	0.4±0.1mm	0.4±0.1mm
Operation	Top-press type	Top-press type
Welding type	SMD	SMD
Live-fire type	Surface mount	Surface mount
Maximum rating	DC 12V/50mA	DC 12V/50mA
Contact resistance (<mΩ)	500mΩ max.	500mΩ max.
Insulation resistance (MΩ at 100V DC)	DC100V 60S 100MΩ min.	DC100V 60S 100MΩ min.
Withstanding voltage	AC250V(50~60HZ) 60S min.	AC250V(50~60HZ) 60S min.
Response time	<10ms (ON, OFF)	<10ms (ON, OFF)
Operating force	160gf	250gf
Stroke	Short stroke	Short stroke
Stroke (mm)	0.13±0.05mm	0.13±0.05mm
Operating life	100000 or more	100000 or more
Operating temperature	–40℃～+90℃	–40℃～+90℃
Storage temperature	–40℃～+90℃	–40℃～+90℃
Package style	Reel packaging	Reel packaging
Mini pakage	10000PCS/reel	10000PCS/reel
Mini pakage
CTNS/QTY	12reel/ctn	12reel/ctn

Dimensions:

Welding diagram:

Circuit diagram:

Key words : Top push Switch,1TS017D,Reference alternative EVQ6P6B40,EVQ9P6B40,EVQP6DB35,EVQP6PB35,SKRWADE030,SKRWAEE030,LS17
